BS450G3
4U general-purpose storage server equipped with dual-socket 3rd Generation Intel® Xeon® Scalable processors; supports 16 ECC DDR4-3200 memory slots and 2 dedicated Intel® Optane™ persistent memory slots; features 36 hot-swappable SAS3/SATA3 drive bays (including 4 hybrid NVMe bays), 2 rear SATA bays, and 1 SATA/NVMe M.2 slot, delivering outstanding data storage capacity.
Model_RefBS450G3
Category_Id存儲
Build_Status: OnlineUUID: 19
Status: AvailableBUILD_UUID: 19
Specifications
| Form Factor / Form Factor | 4U Rackmount |
|---|---|
| Processor / Processor | 3rd Gen Intel Xeon Scalable Processor;Support CPU TDP Up to 270W |
| Socket / Socket | 2 Socket P+ (LGA-4189) |
| Chipset / Chipset | Intel C621A |
| Memory / Memory | Up to 16 DIMM slots Up to 4TB: 16x 256GB DRAM |
| Memory Type / Memory Type | Support 3200MHz ECC DDR4 RDIMM or LRDIMM |
| Storage / Storage | 36x 3.5" hot-swap SATA3/SAS3 drive bays ; 2x 2.5“ SATA drive bays ; 1 M.2 NVMe/SATA |
| PCIe Slots / PCIe Slots | 3 PCIe 4.0 x16 LP slots 1 PCIe 4.0 x8 LP slots |
| Network / Network | 2x 10GbE BaseT |
| PSU / PSU | 2x 1600W Redundant Titanium Power SupplyLevel Power Supply Unit |
| Dimensions / Dimensions | Height: 178 mm (7") Width: 437 mm (17.2") Depth: 698 mm (27.5") |
